Doors and Locks

Door Locks

Locking, Unlocking with Touch Sensor, Door Handle (With the advanced keyless function)

By touching the sensing area of the touch sensor, various locking/unlocking operations can be done without taking the key out of a bag or pocket.

There are two types of touch sensors used for locking and unlocking, and each sensor is built into the outer door handle on the driver and front passenger's doors.

  1. Sensing area of door lock touch sensor (Depression on outer side of door handle)

  2. Sensing area of door release touch sensor (Inner side of door handle)




  • When locking/unlocking with the transmitter carried, securely touch the sensing area of the touch sensor as follows.

    Locking

    Unlocking

  • The system may not operate normally under the following conditions.

    • You touch the sensing area of the door lock touch sensor and the sensing area of the door release touch sensor at the same time.

    • You touch the sensing area of the touch sensor while wearing gloves.

    • Foreign matter such as snow or dirt is stuck on the sensing area of the touch sensor.

    • You pull the door handle just after touching the sensing area of the touch sensor.

  • The system may operate if the outer side door handle of a front door is splashed with water by a car wash or rain while the transmitter is in the operation range.

  • If the system does not operate even though you touch the sensing area of the touch sensor correctly, release the touch sensor once, and then touch the sensing area of the touch sensor again after waiting about 3 seconds.

Locking

When locking, touch the sensing area of the door lock touch sensor with all of the following conditions met.

  • The ignition is switched OFF.

  • All the doors are closed.

  • You are carrying the transmitter.

The following locations are locked by touching the sensing area of the door lock touch sensor.

  • All doors

  • Fuel-filler lid

  • Liftgate

When locking, the hazard warning lights and sound operate one time.

Unlocking

When unlocking, touch the sensing area of the door release touch sensor with all of the following conditions met.

  • The ignition is switched OFF.

  • The driver’s door is locked.

  • Three seconds or longer have passed since the doors were locked.

  • You are carrying the transmitter.

(Unlocking from the driver's door)

The following locations are unlocked by touching the sensing area of the door release touch sensor of the driver's door.

  • Driver’s door

  • Fuel-filler lid




  • The location to be unlocked can be changed.

    Refer to the Settings section in the Mazda Connect Owner's Manual.

When unlocking, the hazard warning lights and sound operate two times.



(Unlocking from the front passenger’s door)

The following locations are unlocked by touching the sensing area of the door release touch sensor of the front passenger's door.

  • All doors

  • Fuel-filler lid

  • Liftgate

When unlocking, the hazard warning lights and sound operate two times.




  • Confirm that all the doors and liftgate/trunk lid are securely locked.

    For the liftgate/trunk lid, move it without pressing the electric liftgate/trunk lid opener to verify that the liftgate/trunk lid has not been left ajar.

  • A beep sound is heard for confirmation when the doors, fuel-filler lid, and liftgate are locked/unlocked using the touch sensor. If you prefer, the beep sound can be turned off.

    The volume of the beep sound can also be changed. Refer to the Settings section in the Mazda Connect Owner's Manual.

  • (With theft-deterrent system)

    The hazard warning lights flash when the theft-deterrent system is armed or turned off.

    Refer to Theft-Deterrent System (Search).

  • The setting can be changed so that the doors, fuel-filler lid, and liftgate are locked automatically without touching the sensing area of the touch sensor.

    Refer to the Settings section in the Mazda Connect Owner's Manual.

    (Walk-away auto lock function)

    A beep sound is heard when all doors and the liftgate/trunk lid are closed while the transmitter is being carried. All the doors, fuel-filler lid, and liftgate are locked automatically when the transmitter is out of the operational range. Also, the hazard warning lights flash once. (Even if the driver is in the operational range, all the doors, fuel-filler lid, and liftgate are locked automatically after about 30 seconds.) If you are out of the operational range before the doors and the liftgate/trunk lid are completely closed or another transmitter is left in the vehicle, the walk-away auto lock function will not work. Always make sure that all doors and the liftgate/trunk lid are closed and locked before leaving the vehicle. The walk-away auto lock function does not close the power windows.

  • (Auto re-lock function)

    After unlocking with the touch sensor, all the doors , fuel-filler lid, and liftgate will automatically lock if any of the following operations are not performed within about 60 seconds.

    • Opening a door or the liftgate/trunk lid.

    • Switching the ignition to any position other than off.

    If your vehicle has a theft-deterrent system, the hazard warning lights will flash for confirmation.

    The time required for the doors to lock automatically can be changed.

    Refer to the Settings section in the Mazda Connect Owner's Manual.

Locking, Unlocking with Door-Lock Switch

Door-lock switch on driver’s and front passenger's door

The following locations are locked/unlocked by pressing the door-lock switch.

  • All doors

  • Fuel-filler lid

  • Liftgate

Driver's door

  1. Unlock

  2. Lock

Front passenger's door

  1. Unlock

  2. Lock




  • To prevent the transmitter from being left in the vehicle, make sure that you carry the transmitter before locking.

  • After locking by pressing the door-lock switch and when the liftgate/trunk lid is closed last with the transmitter left in the vehicle, only the liftgate/trunk lid is unlocked.

Locking from the outside using the door-lock switch

Doors can be locked from the outside of the vehicle without using the transmitter.

When locking from the outside using the door-lock switch, press the lock side of the door-lock switch with all of the following conditions met and then close all the doors.

  • The ignition is switched OFF.

  • Any door is open.




  • To prevent the transmitter from being left in the vehicle, make sure that the driver carries the transmitter when locking the doors with any door open.

  • After locking by pressing the door-lock switch and when all the doors are closed with the transmitter left in the vehicle, all the doors, liftgate, and fuel-filler lid are unlocked.



Door-lock switch on liftgate (With the advanced keyless function)

All doors, fuel-filler lid, and the liftgate can be locked by pressing the door-lock switch.



When locking using the door-lock switch, press the door-lock switch with all of the following conditions met and then close the liftgate.

  • You are carrying the transmitter.

  • The ignition is switched OFF.

  • All the doors are closed.

(With theft-deterrent system)

When locking, a beep sound operates 1 time.

When the liftgate closes, the hazard warning lights operate 1 time.



(Without theft-deterrent system)

When locking, the hazard warning lights and a beep sound operate 1 time.




  • To prevent the transmitter from being left in the vehicle, make sure that you carry the transmitter before locking.

  • After locking by pressing the door-lock switch and when the liftgate is closed with the transmitter left in the vehicle, the liftgate is unlocked.

Locking, Unlocking with Door-Lock Knob

Operation from inside

To lock any door from the inside, press the door-lock knob.

To unlock, pull it outward.

This does not operate the other door locks.



  1. Unlocked: Red indicator

  2. Lock

  3. Unlock



Operation from outside

To lock any door using its door-lock knob from the outside, press the door-lock knob to the lock position and close the door (holding the door handle in the open position is not required).

This does not operate the other door locks.






When locking the door this way:

  • Be careful not to leave the key inside the vehicle. Make sure that you are carrying the key before closing the doors.

  • The doors cannot be locked using the driver's door lock knob if any door or liftgate is open when the ignition is switched to ACC or ON.

  • All the doors, fuel-filler lid , and liftgate are unlocked when the lock knob on all the doors is pressed down to the lock side and all the doors are closed with the transmitter left in the vehicle.

Rear Door Child Safety Locks

Rear doors that have been locked using the child safety lock switched to the lock side cannot be opened from inside the vehicle.

For child safety, switch the child safety lock on both rear doors to the lock side.

When opening a rear door with the child safety lock switched to the lock side, pull the outer door handle with the lock knob inside the vehicle switched to the unlock side.

  1. Auxiliary key (Search)

  2. Lock

  3. Unlock

Liftgate/Trunk Lid




Never allow a person to ride in the luggage compartment/trunk:

Allowing a person to ride in the luggage compartment/trunk is dangerous. The person in the luggage compartment/trunk could be seriously injured or killed during sudden braking or a collision.

Do not drive with the liftgate/trunk lid open:

Exhaust gas in the cabin of a vehicle is dangerous. An open liftgate/trunk lid in a moving vehicle will cause exhaust gas to be drawn into the cabin. This gas contains CO (carbon monoxide), which is colorless, odorless, and highly poisonous, and it can cause loss of consciousness and death. Moreover, an open liftgate/trunk lid could cause occupants to fall out in an accident.

Do not stack or leave loaded luggage unsecured in the luggage compartment:

Otherwise, the luggage may move or collapse, resulting in injury or an accident. In addition, do not load luggage higher than the seatbacks. It may affect the side or rear field of view. Additionally, if the air bags deploy, the cargo may scatter which could result in serious injury or death.




  • Before opening the liftgate/trunk lid, remove any snow and ice accumulation on it. Otherwise, the liftgate/trunk lid could close under the weight of the snow and ice resulting in injury.

  • Be careful when opening/closing the liftgate/trunk lid during strong winds. If a strong gust blows against the liftgate/trunk lid, it could close suddenly resulting in injury.

  • Fully open the liftgate/trunk lid and make sure that it stays open. If the liftgate/trunk lid is only opened partially, it could slam shut by vibration or wind gusts resulting in injury.

  • When loading or unloading luggage in the luggage compartment/trunk, turn off the engine. Otherwise, you could get burned by the heat of the exhaust gas.

  • Be careful not to apply excessive force to the damper stay on the liftgate such as by putting your hand on the stay. Otherwise, the damper stay may bend and affect the liftgate operation.

    1. Damper stay

  • Do not modify or replace the liftgate damper stay. Consult an Authorized Mazda Dealer if a liftgate damper stay is deformed or damaged for reasons such as a collision or if there is some other problem.

Inside Trunk Release Lever

Your vehicle is equipped with an inside trunk release lever that provides a means of escape for children and adults in the event they become locked inside the trunk.



No matter how careful adults might be with keys and locking their cars, parents should be aware that children may be tempted to play around vehicles and use the trunk as a hiding place.



Adults are advised to familiarize themselves with the operation and location of the inside trunk release lever so that all children can be told about it in an appropriate way, keeping in mind that most vehicles do not have such levers.




Close the trunk lid, be sure the seat backs are latched and do not allow children to play inside the vehicle:

Leaving the trunk lid open or leaving children in the vehicle with the keys is dangerous. Children could open the trunk lid and climb inside resulting in possible injury or death from heat exposure.

Always keep the car from being a tempting place to play by latching the rear seats, doors and the trunk, and keeping the keys where children can not play with them:

Leaving children or animals unattended in a parked vehicle is dangerous. Babies left sleeping and children who lock themselves in cars or trunks can die very quickly from heat prostration. Do not leave your children or pets alone in a car at any time. Do not leave the car, the rear folding seats or the trunk unlocked.
