i-ACTIVSENSE

The Adaptive Front Lighting System (AFS) can be switched to on/off using the personalization function.

Refer to the Settings section in the Mazda Connect Owner's Manual.

Speed limit signs

• When the vehicle speed is about 1 km/h (0.6 mph) or faster, the speed limit sign is displayed when any one of the following conditions are met.

  • The Forward Sensing Camera (FSC) recognizes a speed limit sign as a sign targeted for your vehicle and the vehicle passes it.

  • The speed limit sign stored in the navigation system is read.

• In the following cases, display of the speed limit sign stops.

  • Each sensor determines that the vehicle has changed direction of travel.

  • The Forward Sensing Camera (FSC) recognizes a new speed limit sign which differs from the previous one (displays the new speed limit sign).

  • The speed limit sign stored in the navigation system is not read within a certain period of time (if the Forward Sensing Camera (FSC) does not recognize a speed limit sign, the speed limit sign stored in the navigation system is displayed).

  • The vehicle is driven a certain distance while the vehicle speed exceeds the displayed speed limit sign by a certain speed or faster.

Do not enter signs

• A do not enter sign is displayed when all of the following conditions are met.

  • The vehicle speed is about 60 km/h (37 mph) or slower.

  • The Forward Sensing Camera (FSC) recognizes a do not enter sign as a sign targeted for your vehicle and the vehicle passes it.

• When the Forward Sensing Camera (FSC) recognizes the do not enter sign and a certain period of time has elapsed since the vehicle passed the sign, display of the do not enter sign stops.

Stop sign

• A stop sign is displayed when all of the following conditions are met:

  • The vehicle speed is about 65 km/h (40 mph) or slower.

  • The Forward Sensing Camera (FSC) recognizes a stop sign as a sign targeted for your vehicle.

• When a certain period of time has elapsed since the stop sign was displayed, display of the stop sign stops.

• In the following cases, the excessive speed warning stops operating.

  • The vehicle speed is less than the speed of the displayed speed limit sign. (If the activation timing for the excessive speed warning is changed in the personalization features, the excessive speed warning stops operating when the vehicle speed is less than the changed vehicle speed.

  • A speed limit sign indication has been updated and the vehicle speed is lower than the updated indication.

  • Display of the speed limit sign stops.

• The warning indication is displayed at the same time the excessive speed warning sound is activated if the vehicle speed exceeds the speed indicated on the speed limit sign.

  Refer to Excessive Speed Warning (Search).

• If the Forward Sensing Camera (FSC) or data recorded in the navigation system incorrectly recognizes the actual speed limit sign at a lower speed, the excessive speed alarm is activated even if the vehicle is driven at the legal speed.

The system may not operate normally under the following conditions.

• A condition under which the forward sensing camera (FSC) cannot detect a target object is met.

  Refer to Forward Sensing Camera (FSC) (Search).

• The visibility of white (yellow) lines is poor (due to paint flaking or dirt, or being hidden by vehicles ahead).

• There are multiple white (yellow) lines or they are interrupted.

• A misleading line on the road is picked up (such as temporary line for construction, shadow, lingering snow, or grooves filled with water).

• The width of a lane is excessively narrow.

• The vehicle is shaken after hitting a road bump.

• The vehicle is driven on a section with a closed lane or temporary lane due to construction.

• The vehicle is driven on a forked road or junction.

• The Road Keep Assist function may not operate normally when any of the following conditions is met.

  • A condition under which the Forward Sensing Camera (FSC) cannot detect a target is met.

    Refer to Forward Sensing Camera (FSC) (Search).

  • The target objects are difficult to detect (due to low road curb, no contrast between the inside and outside of the road, or being hidden by vehicles ahead).

  • A misleading line (such as temporary line for construction, shadow, lingering snow, or grooves filled with water) is recognized as a target object.

  • The road width is narrow.

  • The vehicle is shaken after hitting a road bump.

• When the ELK OFF indicator light is on, the system is canceled according to a Mazda Connect setting.

  Refer to the Settings section in the Mazda Connect Owner's Manual.



• When the system detects target objects on one side only, the system does not operate to avoid a road departure in the direction of the side that is not being detected.

• If the driver operates the steering wheel while the steering wheel operation assist is operating, the steering wheel operation assist is canceled.

• When the steering wheel operation assist is performed several times within a certain period of time, the warning sound is activated.

During the SBS brake control, the brake pedal may move rearward or become stiff. The brakes are operating, but continue to depress the brake pedal.

• When any of the following conditions is met, the forward detection function may not operate.

  • If there is the possibility of hitting only a part of a vehicle or obstruction ahead.

  • You are driving your vehicle at the same speed as the vehicle ahead.

  • When the driver deliberately performs driving operations (accelerator operation, steering wheel operation).

  • The accelerator pedal is depressed abruptly.

  • The brake pedal is depressed.

  • The steering wheel is being operated.

  • The selector lever is being shifted.

  • The turn signal lever is being operated.

  • Warnings and messages, such as a dirty windshield, related to the Forward Sensing Camera (FSC) or front radar sensor are being displayed on the multi-information display.

• When any of the following conditions is met, the forward detection function may operate.

  • There is an object in the road at the entrance to a curve (including guardrails and snow banks).

  • Passing an approaching vehicle while rounding a curve.

  • When crossing a narrow bridge, going under a low overhang, or passing through a narrow gate, a car washing machine, or tunnel.

  • When passing through a toll gate.

  • When entering an underground parking area.

  • There is a metal object, bump, or a protruding object on the road.

  • If you suddenly come close to a vehicle ahead.

  • An animal, wall, or standing tree is detected.

• While the system is operating, the driver is notified by the multi-information display and the active driving display.

• If a malfunction is detected or the system temporarily stops the function due to dirt on the sensors or cameras, the i-ACTIVSENSE warning light turns on and a message is displayed on the multi-information display.

• If the system performs brake control and the vehicle is stopped, the system will continue to hold the brakes for a brief time unless there is an operation performed by the driver.

• During brake control and brake assist operation, the collision warning sound is activated intermittently.

• The operation distance and volume of the collision warning can be changed.

  Refer to the Settings section in the Mazda Connect Owner's Manual.

During the SBS brake control, the brake pedal may move rearward or become stiff. The brakes are operating, but continue to depress the brake pedal.

• When any of the following conditions is met, the rearward detection function may not operate.

  • Directly after the EV system starts.

  • The height of the obstruction is low such as low walls or trucks with low loading platforms.

  • The height of the obstruction is high such as trucks with high loading platforms.

  • The obstruction is not as large as a vehicle or wall.

  • The obstruction is thin such as a signpost.

  • The surface of the obstruction is not pointed vertically relative to your vehicle.

  • The obstruction is soft such as a hanging curtain or snow stuck to a vehicle.

  • The obstruction is shaped irregularly.

  • The obstruction is extremely close.

• When any of the following conditions is met, the rearward detection function may not operate normally.

  • Snow, ice, or mud adheres to the area around a rear ultrasonic sensor.

  • The vehicle posture is unstable due to sudden operation of the steering wheel, accelerator pedal, or brake pedal.

  • There is another obstruction near one obstruction.

  • During inclement weather such as rain, fog, and snow.

  • High or low humidity.

  • High or low temperatures.

  • Strong winds.

  • The path of travel is not flat.

  • Heavy luggage is loaded in the luggage compartment or on the rear seat and the vehicle is tilted.

  • Objects such as a wireless antenna, fog light, or illuminated license plate is installed near a rear ultrasonic sensor.

  • The orientation of a rear ultrasonic sensor has deviated for reasons such as a collision.

  • The vehicle is affected by other sound waves such as the horn, engine noise, or rear ultrasonic sensor of another vehicle.

• When any of the following conditions is met, the rearward detection function may operate.

  • Reversing towards a steep ascending slope.

  • There are grating, wheel blocks, a road curb, or a bump.

  • There is a hanging curtain or railroad crossing gate.

  • Reversing near objects such as foliage, barriers, vehicles, walls, or fences.

  • The vehicle is driven on rough roads such as in areas where there is grass and foliage or off-road.

  • When reversing through low gates, narrow gates, car washing machines, tunnels, or into a mechanical parking garage.

  • A towing bar is installed or a trailer is connected.

• If the system performs brake control and the vehicle is stopped, the system will continue to hold the brakes for a brief time unless there is an operation performed by the driver.

During brake control, the collision warning sound is activated intermittently.

• When any of the following conditions is met, the i-ACTIVSENSE warning indication/warning light is turned on and the system operation is stopped. If the i-ACTIVSENSE warning indication/warning light remains on, have the vehicle inspected by an Authorized Mazda Dealer as soon as possible.

  • There is a problem with the system.

  • A large deviation in the installation position of a rear side radar sensor on the vehicle has occurred.

  • Snow, ice, or mud is adhering around a rear side radar sensor.

  • The temperature around a rear side radar sensor is high.

  • Driving on snow-covered roads for long periods.

  • The lead-acid battery voltage has decreased.

• When any of the following conditions is met, the Rear Crossing detection function will not detect approaching vehicles or they may be difficult to detect.

  • The rear side radar sensor detection area is obstructed by a nearby wall or parked vehicle. (Reverse the vehicle to a position where the radar sensor detection area is no longer obstructed.)



    1. Your vehicle



  • A vehicle is approaching directly from the rear of your vehicle.



    1. Your vehicle



  • The vehicle is parked on a slant.



    1. Your vehicle



  • A vehicle is approaching from the opposite direction on a steep gradient.



    1. Your vehicle



  • Directly after the EV system starts.

  • Just after the SBS operation has been enabled using [Settings] in Mazda Connect.

  • Radio wave interference from a radar sensor equipped on a vehicle parked nearby.

• When any of the following conditions is met, the Rear Crossing may operate.

  • There is a hanging curtain or railroad crossing gate.

  • Reversing near objects such as foliage, barriers, vehicles, walls, or fences.

  • The vehicle is driven on rough roads such as in areas where there is grass and foliage or off-road.

  • When reversing through low gates, narrow gates, car washing machines, or tunnels.

  • A towing bar is installed or a trailer is connected.

• If the system performs brake control and the vehicle is stopped, the system will continue to hold the brakes for a brief time unless there is an operation performed by the driver.

During brake control, the collision warning sound is activated intermittently.

When the power switch is switched OFF while the SBS forward drive detection is canceled, the SBS forward drive detection is automatically enabled the next time the power switch is switched ON.
