Instrument Cluster

1. Tachometer

2. Multi-information Display

3. Engine Coolant Temperature Gauge

4. Fuel Gauge

5. Dashboard Illumination Switch

6. Speedometer

7. TRIP Switch

The display changes each time the TRIP switch is pressed.

1. Odometer display

2. Trip meter A display

3. Trip meter B display

When returning the trip meter to “0”, press the TRIP switch for 2 seconds or longer while the trip meter is displayed.



---

If the lead-acid battery is disconnected for vehicle maintenance or other reasons, the trip meter display returns to “0”.

Close Note

View Note

When the vehicle power is switched ON, the outside temperature is displayed.



---

The outside temperature display may differ from the actual outside temperature depending on the surroundings and vehicle conditions.

Close Note

View Note

This displays the current fuel economy by calculating the amount of fuel consumption and the distance traveled.

(e-SKYACTIV G)

(SKYACTIV-G)



---

• Displays the 0 position when the vehicle speed decreases to a constant speed or slower.

• The arrow on the scale indicates the average fuel economy.
