Owner Maintenance

The owner or a qualified service technician should make these vehicle inspections at the indicated intervals to ensure safe and dependable operation.

Bring any problem to the attention of an Authorized Mazda Dealer or qualified service technician as soon as possible.

When Charging the Vehicle

• Brake fluid level (Search)

• Coolant level (Search)

• Washer fluid level (Search)

• Lead-acid Battery Maintenance (Search)

At Least Monthly

• Tire inflation pressures (Search)

At Least Twice a Year (For Example, Every Spring and Fall)

You can do the following scheduled maintenance items if you have some mechanical ability and a few basic tools and if you closely follow the directions in this manual.

• Coolant (Search)

Improper or incomplete service may result in problems. This section gives instructions only for items that are easy to perform.

As explained in the Introduction (Search), several procedures can be done only by a qualified service technician with special tools.

Improper owner maintenance during the warranty period may affect warranty coverage. Refer to Introduction (Search) for owner's responsibility in protecting your investment. For details, read the separate Mazda Warranty statement provided with the vehicle. If you are unsure about any servicing or maintenance procedure, have it done by an Authorized Mazda Dealer.

There are strict environmental laws regarding the disposal of waste fluids. Please dispose of your waste properly and with due regard to the environment.

We recommend that you entrust the fluid changes of your vehicle to an Authorized Mazda Dealer.



---

Do not perform maintenance work if you lack sufficient knowledge and experience or the proper tools and equipment to do the work. Have maintenance work done by a qualified technician:

Performing maintenance work on a vehicle is dangerous if not done properly. You can be seriously injured while performing some maintenance procedures.

If you must run the EV system while working under the hood, make certain that you remove all jewelry (especially rings, bracelets, watches, and necklaces) and all neckties, scarves, and similar loose clothing before getting near the cooling fan which may turn on unexpectedly:

Working under the hood with the EV system operating is dangerous. It becomes even more dangerous when you wear jewelry, loose clothing or have long hair or a long beard.

Either can become entangled in moving parts and result in injury.

Pull over to a safe location, then switch the power switch off and make sure the fan is not running before attempting to work near the cooling fan:

Working near the cooling fan when it is running is dangerous. The fan could continue running indefinitely even if the EV system has stopped and the motor compartment temperature is high. You could be hit by the fan and seriously injured.

Do not leave items in the motor compartment:

After you have finished checking or doing servicing in the motor compartment, do not forget and leave items such as tools or rags in the motor compartment.

Tools or other items left in the motor compartment could cause EV system damage or a fire leading to an unexpected accident.

Close Warning

View Warning

1. With the vehicle parked, pull the release handle to unlock the hood.





2. Insert your hand into the hood opening, slide the latch lever in the direction of the arrow as shown in the illustration, and lift up the hood.







3. Grasp the support rod in the padded area and secure it in the support rod hole indicated by the arrow to hold the hood open.





   1. Pad

   2. Support rod

1. Check under the hood area to make certain all filler caps are in place and all loose items (e.g. tools, oil containers, etc.) have been removed.

2. Lift the hood, grasp the padded area on the support rod, and secure the support rod in the clip. Verify that the support rod is secured in the clip before closing the hood.





   1. Clip



3. Lower the hood slowly to a height of about 20 cm (7.9 in) above its closed position and then let it drop.



---

When closing the hood, do not push it excessively such as by applying your weight. Otherwise, the hood could be deformed.

Close Caution

View Caution



---

Do not use a match or live flame in the motor compartment. DO NOT ADD COOLANT WHEN THE EV SYSTEM IS HOT:

A hot EV system is dangerous. If the EV system has been running, parts of the motor compartment can become very hot. You could be burned. Carefully inspect the coolant in the coolant reservoir, but do not open it.

Pull over to a safe location, then switch the power switch off and make sure the fan is not running before attempting to work near the cooling fan:

Working near the cooling fan when it is running is dangerous. The fan could continue running indefinitely even if the EV system has stopped and the motor compartment temperature is high. You could be hit by the fan and seriously injured.

Do not remove either cooling system cap when the EV system and radiator are hot:

When the EV system and radiator are hot, scalding coolant and steam may shoot out under pressure and cause serious injury.

Close Warning

View Warning



---

Changing the coolant should be done by an Authorized Mazda Dealer.

Close Note

View Note

Inspect the antifreeze protection and coolant level in the coolant reservoir at least once a year―at the beginning of the winter season―and before traveling where temperatures may drop below freezing.

Inspect the condition and connections of the cooling system.

Replace any that are swollen or deteriorated.

The coolant should be between the FULL and LOW marks on the coolant reservoir when the EV system is cool.

If it is at or near LOW, add enough coolant to the coolant reservoir to provide freezing and corrosion protection and to bring the level to FULL.

Securely tighten the coolant reservoir tank cap after adding coolant.



---

• Radiator coolant will damage paint.

  Rinse it off quickly if spilled.

• If the “FL22” mark is shown on or near the cooling system cap, use of FL-22 is recommended when replacing coolant. Using coolant other than FL-22 may cause serious damage to the cooling system.



Close Caution

View Caution

If the coolant reservoir is empty or new coolant is required frequently, consult an Authorized Mazda Dealer.



---

If the brake fluid level is low, have the brakes inspected:

A low brake fluid level is dangerous.

A low level could indicate brake lining wear or a brake system leak which could cause the brakes to fail and lead to an accident.

Close Warning

View Warning

Inspect the fluid level in the reservoir regularly. It should be kept between the MAX and MIN lines.

The level normally drops with accumulated distance, a condition associated with wear of brake linings. If it is excessively low, have the brake system inspected by an Authorized Mazda Dealer.



---

Use only windshield washer fluid or plain water in the reservoir:

Using radiator antifreeze as washer fluid is dangerous. If sprayed on the windshield, it will dirty the windshield, affect your visibility, and could result in an accident.

Using Washer Fluid Without Anti-freeze Protection in Cold Weather:

Operating your vehicle in temperatures below 4 °C (40 °F) using washer fluid without anti-freeze protection is dangerous as it could cause impaired windshield vision and result in an accident. In cold weather, always use washer fluid with anti-freeze protection.

Close Warning

View Warning



---

State or local regulations may restrict the use of volatile organic compounds (VOCs), which are commonly used as anti-freeze agents in washer fluid. A washer fluid with limited VOC content should be used only if it provides adequate freeze resistance for all regions and climates in which the vehicle will be operated.

Close Note

View Note

Add washer fluid under any of the following conditions.

• The top of the fluid level is low.

• The Low Washer Fluid Level Warning Indication/Warning Light (if equipped) turns on.

• The top of the fluid level is lower than E (if equipped).



Use plain water if washer fluid is unavailable.

But use only washer fluid in cold weather to prevent it from freezing.



---

Front and rear washer fluid is supplied from the same reservoir.

Close Note

View Note

All moving points on the vehicle body, such as door and hood hinges and locks, should be lubricated to move smoothly.

Use a non-freezing lubricant on locks during cold weather.

Make sure the hood's secondary latch keeps the hood from opening when the primary latch is released.

When the wipers no longer clean well, the blades are probably worn or cracked.

Replace them.



---

• To prevent damaging a windshield wiper blade, wiper arm, or the hood, perform the following procedure.

  • Before lifting the windshield wiper blades off the windshield, always move them to the service position.

  • When putting the windshield wiper blades back on the windshield, make sure that they are in the service position before switching the power switch ON and operating the windshield wipers.

• Replace with Mazda genuine wiper blades. If they are replaced with wiper blades other than a Mazda genuine product, they may not wipe with the same efficiency as the genuine product.

• To prevent damage to the wiper arms and other components, do not try to sweep the wiper arm by hand.

• Do not bend the blade rubber unnecessarily when replacing it. Otherwise, the metal stiffener in the blade may deform and the windshield wiper operation may be adversely affected.

• Do not hold a wiper blade by its end when raising the wiper arm. Otherwise, the part may deform and the wiping performance may lower.

• Forcefully lowering the wiper arms could damage the wiper arm and blade, and may scratch or crack the windshield.

Close Caution

View Caution



---

You can replace the wiper blades yourself, however you cannot replace the wiper arms.

If you want to replace the wiper arms, consult an Authorized Mazda Dealer.

Close Note

View Note

Replace the wiper blades using the following procedure.

1. Move the wipers to the service positions using the following procedure.

   1. Switch the power switch ON.

   2. Switch the power switch OFF.

   3. Press up the wiper switch to the MIST position 2 times within 30 seconds after switching the power switch OFF.

      When the procedure is completed, the wipers operate and they stop at the service positions.

2. Raise the wiper arms.

3. Slide the blade component in the direction of the arrow while pressing the wiper arm tab to remove the blade component from the wiper arm.





4. Pull the blade rubber in the direction of the arrow and slide it to a position where the blade holder groove can be checked.





5. Pull the end of the blade rubber from the blade holder groove in the direction of the arrow and remove the blade rubber from the blade holder.





6. Insert the end of the new blade rubber into the groove of the blade holder until it contacts the end of the blade holder.





7. After pulling the blade rubber in the direction of the arrow and sliding the blade rubber to a position to check the blade holder groove, slide the blade rubber end in the opposite direction.





8. Make sure that the blade rubber is correctly installed to the blade holder.

9. Slide the blade component and install it to the wiper arm.





10. Slowly lower the wiper arms onto the windshield.



    ---

    To prevent damage to the windshield let the wiper arm down easily, do not let it slap down on the windshield.

    Close Caution

    View Caution

11. Move the wipers to their initial positions using the following procedure.

    1. Make sure that the wipers are set on the windshield.

    2. Switch the power switch ON.

    3. Press up the wiper switch to the MIST position 1 time.

       When the procedure is completed, the wipers operate and they stop at the initial positions.

To get the best service from a lead-acid battery:

• Keep it securely mounted.

• Keep the top clean and dry.

• Keep terminals and connections clean, tight, and coated with petroleum jelly or terminal grease.

• Rinse off spilled electrolyte immediately with a solution of water and baking soda.

• If the vehicle will not be used for an extended time, disconnect the lead-acid battery cables and charge the lead-acid battery every 6 weeks.

If the buttons on the transmitter are inoperable and the operation indicator light does not flash, the battery may be dead.

Replace with a new battery before the transmitter becomes unusable.



---

• Make sure the battery is installed correctly. Battery leakage could occur if it is not installed correctly.

• When replacing the battery, be careful not to touch any of the internal circuitry and electrical terminals, bend the electrical terminals, or get dirt in the transmitter as the transmitter could be damaged.

• There is the danger of explosion if the battery is not correctly replaced.

• Dispose of used batteries according to the following instructions.

  • Insulate the plus and minus terminals of the battery using cellophane or equivalent tape.

  • Never disassemble.

  • Never throw the battery into fire or water.

  • Never deform or crush.

• Replace only with the same type battery (CR2032 or equivalent).

Close Caution

View Caution

The following conditions indicate that the battery power is low:

• A message, “Low Key Fob Battery. Replace Battery” is displayed on the multi-information display when the power switch is switched OFF.

• The system does not operate and the operation indicator light on the transmitter does not flash when the buttons are pressed.

• The system's operational range is reduced.

Incorrect battery replacement operation may damage the key. Replacing the battery at an Authorized Mazda Dealer is recommended. If replacing the battery by yourself, follow the instruction.

Replacing the key battery

1. Remove the lower cover while sliding the knob in the direction of the arrow.



2. Press in the tab to unlock the upper cover.



3. Insert a tape-wrapped flathead screwdriver into the gap and slide it in the direction of the arrow.



4. Twist the flathead screwdriver in the direction of the arrow and remove the upper cover.



5. Remove the cap using the tape-wrapped flathead screwdriver.



6. Remove the battery using tape-wrapped flathead screwdriver.



7. Insert a new battery into the transmitter so that the positive pole is facing up.

8. Install the cap.



9. Install the upper cover.



10. Insert the tabs of the lower cover into the slots of the transmitter and install the lower cover.



For reasons of proper performance, safety, and better energy efficiency, always maintain recommended tire inflation pressures and stay within the recommended load limits and weight distribution.



---

Using Different Tire Types:

Driving your vehicle with different types of tires is dangerous. It could cause poor handling and poor braking; leading to loss of control.

Except for the limited use of the temporary spare tire, use only the same type tires (radial, bias-belted, bias-type) on all four wheels.

Using Wrong-Sized Tires:

Using any other tire size than what is specified for the vehicle (Search) is dangerous. It could seriously affect ride, handling, ground clearance, tire clearance, and speedometer calibration. This could cause you to have an accident. Use only tires that are the correct size specified for the vehicle.

Close Warning

View Warning



---

Rotate tires periodically:

Irregular tire wear is dangerous. To equalize tread wear for maintaining good performance in handling and braking, rotate the tires periodically or sooner if irregular wear develops.

Please refer to Scheduled maintenance for your tire rotation interval.

Close Warning

View Warning

During rotation, inspect them for correct balance.



---

Because your vehicle is not equipped with a spare tire, you cannot do a tire rotation safely with the jack that comes with your vehicle. Have an Authorized Mazda Dealer perform tire rotation.

Close Note

View Note

1. Forward

Do not include (TEMPORARY USE ONLY) spare tire in rotation.

Also, inspect them for uneven wear and damage. Abnormal wear is usually caused by one or a combination of the following:

• Incorrect tire pressure

• Improper wheel alignment

• Out-of-balance wheel

• Severe braking

After rotation, inflate all tire pressures to specification (Search) and inspect the lug nuts for tightness.



---

Rotate unidirectional tires and radial tires that have an asymmetrical tread pattern or studs only from front to rear, not from side to side. Tire performance will be reduced if rotated from side to side.

Close Caution

View Caution



---

Always use wheels of the correct size on your vehicle:

Using a wrong-sized wheel is dangerous. Braking and handling could be affected, leading to loss of control and an accident.

Close Warning

View Warning



---

A wrong-sized wheel may adversely affect:

• Tire fit

• Wheel and bearing life

• Ground clearance

• Snow-chain clearance

• Speedometer calibration

• Headlight aim

• Bumper height

• Tire Pressure Monitoring System

Close Caution

View Caution



---

• When replacing a wheel, make sure the new one is the same as the original factory wheel in diameter, rim width, and offset (inset/outset).

• For details, contact an Authorized Mazda Dealer.

Close Note

View Note

Proper tire balancing provides the best riding comfort and helps reduce tread wear. Out-of-balance tires can cause vibration and uneven wear, such as cupping and flat spots.

Front

1. Side turn signal lights

2. Front side-marker lights

3. Front turn signal lights/Parking lights

4. Headlights (High/Low beam)/Daytime running lights

Rear

1. High-mount brake light

2. Rear side-marker lights

3. Brake lights/Taillights

4. Rear turn signal lights

5. Reverse lights

6. Taillights (Some Models)

7. License plate lights

All the light bulbs are the LED type.

The LED bulb cannot be replaced as a single unit because it is an integrated unit.

The LED bulb has to be replaced with the unit. If a replacement is necessary, consult an Authorized Mazda Dealer.

Your vehicle's electrical system is protected by fuses.

If any lights, accessories, or controls do not work, inspect the appropriate circuit protector. If a fuse has blown, the inside element will be melted.

If the same fuse blows again, avoid using that system and consult an Authorized Mazda Dealer as soon as possible.
